JLG SkyTrak 8042 Telehandler
Built for demanding material-handling jobs, the JLG SkyTrak 8042 delivers
8,000 lbs. of maximum lift capacity with a maximum lift height of
42′ 4″ and a forward reach of up to 29′ 6″.
A powerful and versatile choice for construction, agriculture, landscaping, and
commercial job sites.
BUILT FOR THE JOB
8,000 lb. Lift Capacity
Provides substantial lifting power for moving and positioning heavy materials around the job site.
Provides substantial lifting power for moving and positioning heavy materials around the job site.
42′ 4″ Lift Height
Reaches elevated work areas for loading, placing materials, framing, construction, and more.
Reaches elevated work areas for loading, placing materials, framing, construction, and more.
29′ 6″ Forward Reach
Provides extended reach for positioning materials where conventional forklifts cannot easily reach.
Provides extended reach for positioning materials where conventional forklifts cannot easily reach.
74 HP Diesel Engine
Powered by a Deutz 2.9L diesel engine designed to deliver dependable performance for demanding applications.
Powered by a Deutz 2.9L diesel engine designed to deliver dependable performance for demanding applications.
4×4 Drive
Four-wheel drive helps provide traction and mobility across challenging construction and outdoor job sites.
Four-wheel drive helps provide traction and mobility across challenging construction and outdoor job sites.
All-Wheel Steering
Improves maneuverability and helps the machine navigate tight work areas and demanding job-site conditions.
Improves maneuverability and helps the machine navigate tight work areas and demanding job-site conditions.
SPECIFICATIONS
Maximum Lift Capacity
8,000 lbs.
8,000 lbs.
Maximum Lift Height
42′ 4″
42′ 4″
Maximum Forward Reach
29′ 6″
29′ 6″
Capacity at Maximum Height
6,000 lbs.
6,000 lbs.
Capacity at Maximum Reach
1,600 lbs.
1,600 lbs.
Engine
Deutz 2.9L Diesel
Deutz 2.9L Diesel
Engine Power
74 HP
74 HP
Drive
4×4
4×4
Transmission
Hydrostatic
Hydrostatic
Maximum Travel Speed
15 MPH
15 MPH
Frame Leveling
±10°
±10°
Operating Weight
Approximately 21,200 lbs.
Approximately 21,200 lbs.
GREAT FOR
CONSTRUCTION
MATERIAL HANDLING
FRAMING
LANDSCAPING
AGRICULTURE
COMMERCIAL JOBS
LIFT HIGH. REACH FAR. GET THE JOB DONE.
With its powerful 8,000 lb. lifting capacity, 42′ 4″ lift height, and
29′ 6″ forward reach, the JLG SkyTrak 8042 is ready to tackle demanding
material-handling projects with confidence.
